1. Product Introduction
Belt-Driven Actuators: The belt-driven actuator operates under the same principles as the conveyor belt system. The
belt drive translates rotary motion to linear motion via a timing belt connected between two circular pulleys.
The timing belt is usually made from a fiber-reinforced elastomeric, but many other belt materials are available for
more demanding applications.
The belt contains teeth that interface with the rotor pulleys to efficiently transfer torque and prevent slipping.
The belt drive is enclosed within an aluminum body while the carriage rides on top, and the driveshaft interface is
typically situated perpendicular to the side of the actuator.
Belt-driven linear actuators are typically used for light to medium duty applications that require higher speeds and
2. Product feature and application：
3. Product qualification:
4. Deliver, shipping and
Our belt drives and actuators are available in three different configurations, allowing engineers to select standard
models for off-the-shelf availability, plug-and-play models for ready out-of-the-box automation, and customer
built models that allow for a wide range of configurations.
Standard Belt Driven Linear Actuators
Standard actuators are available in stock travel lengths and offer users a number of commonly configured options.
Off-the-shelf availability allows for fast delivery while still providing industrial quality for a range of
linear motion and automation applications.
Plug-and-Play Belt Driven Linear Actuators
Plug-and-play actuators and belt drives provide users with ready out-of-the box automation functionality. Each unit
comes complete with actuator/belt drive, a UL approved electric motor, and PLC device. These models are a good
fit for educational and university robotics, or laboratory and research applications.
Custom Belt Driven Linear Actuators
Custom actuators and belt drives deliver the same features as standard models, however, these models allow users to
specify custom specifications including but not limited to cart design, belt options, extrusion size, length and
finish, and any special requirements for gearboxes and motors. The modular design of our belt driven actuators
allows for fast customization to meet most specifications without ordering a totally custom item, ultimately
